2000-2005 Saturn L Series
Locate the BCM and install the PRO Full Bypass The BCM is mounted on the top of the glove box. There are 4 electrical connectors on the BCM. Body Control Module J2
2000-2005 Chevrolet Safari and Astro
Locate the BCM and install the PRO Bypass Module The BCM is behind and above the radio. Remove the radio and the heater control out to gain access to the Body Control Module. here are 3 electrical connectors on the BCM (C1, C2, C3). We will only need to work on C1 and C2. Safari […]
2000-2005 Chevrolet Impala, Monte Carlo
The BCM is under the dash, far left above the parking brake pedal. There are 3 electrical connectors on the BCM (C1 24 pin pink, C2 24 pin grey, C3 16 pin grey) This view is looking into the end that goes into the BODY CONTROL MODULE, so reverse it with the release tab on top. […]
2000-2005 Chevrolet Cavalier, Pontiac Sunfire
The Body Control Module (BCM) is under the left side of the dash. There are 3 connectors for the BCM. C1 is Purple, we don’t need this one. C2 is Light Blue, we need this one. C3 is Brown and we need this one as well.
2000-2002 Saturn SL SW SC Series
Locate the BCM and install the PRO Full Bypass The BCM is mounted on the top of the dash under the pad. 1. Disable the SIR system by taking the battery cables off. Notice: Be careful not to damage the VIN plate when removing or replacing the upper trim panel. Remove the instrument panel upper trim: […]
2000 Oldsmobile Intrigue
The BCM is is under the left side of the dash There are 4 electrical connectors on the BCM we need (C1 BLUE, C2 Purple) C2 Connector Purple C1 Connector blue
1999-2002 Chevrolet Suburban, Silverado, Tahoe, GMC Yukon, Sierra (NEW STYLE)
Locate the BCM The BCM is in the dash directly under the steering column. Remove the Trim panel. Then behind that is the BCM. Disconnect the Brown connector first. There are 3 electrical connectors on the BCM (C1, C2, C3) The connectors we need are C1 which is brown and C2 which is Grey or […]
1998-2005 Chevrolet S10, Blazer, Isuzu Hombre, Oldsmobile Bravada, GMC Envoy, Sonoma, Jimmy
Locate the BCM and install the PRO Bypass Module The BCM is under the drivers side of the dash. Remove the screws from the DLC Plug. REmove the screws that hold the sound insulator. Remove the connectors from the module. Remove the left sound insulator. Remove the center console if equipped. Remove the screws that […]
1998-2002 GMC Savana, Chevrolet Express
Locate the TDM and install the PRO Bypass The TDM (or passlock control module) is in the dash behind the radio area and you can get at it above the fuel pedal. There is 1 electrical connectors on the TDM (or Passlock control module).
1998-2000 Chevrolet Silverado Classic, Sierra, Suburban, Tahoe, GMC Yukon, Cadillac Escalade
Locate the EVO Module and Install the PRO Bypass The EVO Passlock Module is under the center of the dash under the Ashtray. • Remove the knee bolster screws. • Unsnap the knee bolster. • Twist the brake release cable in order to disengage the knee bolster. • Remove the lap cooler hose. • Remove […]
